Python Data Visualization with Matplotlib and Seaborn: Complete Guide

Why Data Visualization Matters

A table of 10,000 numbers tells you nothing. A chart tells a story in seconds. Python’s visualization libraries turn raw data into insights.

import matplotlib.pyplot as plt
import numpy as np

x = np.linspace(0, 10, 100)
plt.plot(x, np.sin(x))
plt.title("Sine Wave")
plt.savefig("sine.png")

Three lines to go from data to chart. Let’s build on this.

Installation

pip install matplotlib seaborn plotly pandas numpy

Matplotlib Fundamentals

Line Charts

import matplotlib.pyplot as plt
import numpy as np

months = ["Jan", "Feb", "Mar", "Apr", "May", "Jun",
          "Jul", "Aug", "Sep", "Oct", "Nov", "Dec"]
sales_2024 = [45, 52, 48, 61, 55, 67, 72, 68, 74, 82, 91, 105]
sales_2025 = [50, 58, 55, 68, 62, 75, 80, 77, 85, 93, 98, 112]

fig, ax = plt.subplots(figsize=(10, 5))
ax.plot(months, sales_2024, marker="o", label="2024", linewidth=2)
ax.plot(months, sales_2025, marker="s", label="2025", linewidth=2)

ax.set_xlabel("Month")
ax.set_ylabel("Sales (thousands)")
ax.set_title("Monthly Sales Comparison")
ax.legend()
ax.grid(True, alpha=0.3)

plt.tight_layout()
plt.savefig("sales_comparison.png", dpi=150)

Bar Charts

categories = ["Python", "JavaScript", "Java", "C++", "Go"]
popularity = [31.5, 18.2, 15.8, 11.3, 8.7]
colors = ["#3776AB", "#F7DF1E", "#ED8B00", "#00599C", "#00ADD8"]

fig, ax = plt.subplots(figsize=(8, 5))
bars = ax.bar(categories, popularity, color=colors, edgecolor="white", linewidth=1.5)

# Add value labels on bars
for bar, val in zip(bars, popularity):
    ax.text(bar.get_x() + bar.get_width() / 2, bar.get_height() + 0.5,
            f"{val}%", ha="center", fontweight="bold")

ax.set_ylabel("Popularity (%)")
ax.set_title("Programming Language Popularity 2026")
ax.spines["top"].set_visible(False)
ax.spines["right"].set_visible(False)

plt.tight_layout()
plt.savefig("language_popularity.png", dpi=150)

Subplots

fig, axes = plt.subplots(2, 2, figsize=(12, 10))

# Subplot 1: Line chart
x = np.linspace(0, 10, 50)
axes[0, 0].plot(x, np.sin(x), color="#e74c3c")
axes[0, 0].set_title("Sine Wave")

# Subplot 2: Scatter plot
np.random.seed(42)
x = np.random.randn(100)
y = x * 2 + np.random.randn(100) * 0.5
axes[0, 1].scatter(x, y, alpha=0.6, c="#3498db")
axes[0, 1].set_title("Scatter Plot")

# Subplot 3: Histogram
data = np.random.normal(100, 15, 1000)
axes[1, 0].hist(data, bins=30, color="#2ecc71", edgecolor="white")
axes[1, 0].set_title("Distribution")

# Subplot 4: Box plot
data = [np.random.normal(m, 10, 100) for m in [60, 70, 80, 90]]
axes[1, 1].boxplot(data, labels=["Q1", "Q2", "Q3", "Q4"])
axes[1, 1].set_title("Quarterly Performance")

plt.tight_layout()
plt.savefig("subplots.png", dpi=150)

Seaborn for Statistical Plots

Seaborn builds on Matplotlib with better defaults and statistical visualizations.

Heatmap

import seaborn as sns
import pandas as pd
import numpy as np

# Correlation matrix
np.random.seed(42)
data = pd.DataFrame({
    "Revenue": np.random.randn(100),
    "Users": np.random.randn(100),
    "Sessions": np.random.randn(100),
    "Bounce Rate": np.random.randn(100),
    "Conversion": np.random.randn(100),
})
data["Conversion"] = data["Revenue"] * 0.7 + np.random.randn(100) * 0.3
data["Sessions"] = data["Users"] * 0.8 + np.random.randn(100) * 0.4

corr = data.corr()

plt.figure(figsize=(8, 6))
sns.heatmap(corr, annot=True, cmap="RdBu_r", center=0,
            fmt=".2f", square=True, linewidths=0.5)
plt.title("Feature Correlation Matrix")
plt.tight_layout()
plt.savefig("heatmap.png", dpi=150)

Distribution Plots

fig, axes = plt.subplots(1, 3, figsize=(15, 5))

# KDE plot
sns.kdeplot(data=data, x="Revenue", fill=True, ax=axes[0], color="#3498db")
axes[0].set_title("Revenue Distribution")

# Violin plot
tips = sns.load_dataset("tips")
sns.violinplot(data=tips, x="day", y="total_bill", ax=axes[1], palette="Set2")
axes[1].set_title("Bills by Day")

# Swarm plot
sns.swarmplot(data=tips, x="day", y="tip", hue="sex", ax=axes[2], palette="Set1", size=4)
axes[2].set_title("Tips by Day and Gender")

plt.tight_layout()
plt.savefig("distributions.png", dpi=150)

Pair Plot

iris = sns.load_dataset("iris")

g = sns.pairplot(iris, hue="species", palette="husl",
                 diag_kind="kde", plot_kws={"alpha": 0.6})
g.fig.suptitle("Iris Dataset Pair Plot", y=1.02)
plt.savefig("pairplot.png", dpi=150)

Regression Plot

tips = sns.load_dataset("tips")

fig, axes = plt.subplots(1, 2, figsize=(12, 5))

sns.regplot(data=tips, x="total_bill", y="tip", ax=axes[0],
            scatter_kws={"alpha": 0.5}, line_kws={"color": "red"})
axes[0].set_title("Tip vs Total Bill")

sns.residplot(data=tips, x="total_bill", y="tip", ax=axes[1],
              scatter_kws={"alpha": 0.5})
axes[1].set_title("Residuals")

plt.tight_layout()
plt.savefig("regression.png", dpi=150)

Plotly for Interactive Charts

import plotly.express as px
import plotly.graph_objects as go

# Interactive scatter plot
df = px.data.gapminder().query("year == 2007")
fig = px.scatter(
    df, x="gdpPercap", y="lifeExp",
    size="pop", color="continent",
    hover_name="country",
    log_x=True,
    title="GDP vs Life Expectancy (2007)"
)
fig.write_html("interactive_scatter.html")

# Interactive line chart with range slider
df = px.data.stocks()
fig = px.line(df, x="date", y=df.columns[1:],
              title="Stock Prices Over Time")
fig.update_xaxes(rangeslider_visible=True)
fig.write_html("stocks.html")

Custom Themes and Styling

Creating a Custom Style

import matplotlib.pyplot as plt

# Define custom style
custom_style = {
    "figure.facecolor": "#1a1a2e",
    "axes.facecolor": "#16213e",
    "axes.edgecolor": "#e94560",
    "axes.labelcolor": "#eee",
    "text.color": "#eee",
    "xtick.color": "#eee",
    "ytick.color": "#eee",
    "grid.color": "#333",
    "grid.alpha": 0.3,
    "font.size": 12,
}

with plt.rc_context(custom_style):
    fig, ax = plt.subplots(figsize=(10, 5))
    x = np.linspace(0, 10, 100)
    ax.plot(x, np.sin(x), color="#e94560", linewidth=2, label="sin(x)")
    ax.plot(x, np.cos(x), color="#0f3460", linewidth=2, label="cos(x)")
    ax.set_title("Dark Theme Chart")
    ax.legend()
    ax.grid(True)
    plt.tight_layout()
    plt.savefig("dark_theme.png", dpi=150)

Seaborn Built-in Themes

themes = ["darkgrid", "whitegrid", "dark", "white", "ticks"]

fig, axes = plt.subplots(1, 5, figsize=(20, 4))
for ax, theme in zip(axes, themes):
    with sns.axes_style(theme):
        x = np.random.randn(100)
        ax.hist(x, bins=20, color="#3498db")
        ax.set_title(theme)

plt.tight_layout()
plt.savefig("seaborn_themes.png", dpi=150)

Dashboard-Style Visualization

Combine multiple charts into a cohesive dashboard:

import matplotlib.pyplot as plt
import matplotlib.gridspec as gridspec
import numpy as np
import pandas as pd

np.random.seed(42)

fig = plt.figure(figsize=(16, 10))
gs = gridspec.GridSpec(3, 3, hspace=0.35, wspace=0.3)

# KPI cards (top row)
kpis = [
    ("Total Revenue", "$1.2M", "+12.5%", "#27ae60"),
    ("Active Users", "48.3K", "+8.2%", "#2980b9"),
    ("Conversion Rate", "3.7%", "-0.3%", "#e74c3c"),
]

for i, (title, value, change, color) in enumerate(kpis):
    ax = fig.add_subplot(gs[0, i])
    ax.text(0.5, 0.7, value, ha="center", va="center",
            fontsize=28, fontweight="bold", color=color)
    ax.text(0.5, 0.35, change, ha="center", va="center",
            fontsize=14, color=color, alpha=0.8)
    ax.text(0.5, 0.1, title, ha="center", va="center",
            fontsize=11, color="#666")
    ax.set_xlim(0, 1)
    ax.set_ylim(0, 1)
    ax.axis("off")

# Revenue trend (middle left)
ax = fig.add_subplot(gs[1, :2])
months = pd.date_range("2025-01", periods=12, freq="M")
revenue = [85, 92, 88, 101, 95, 108, 115, 110, 120, 132, 141, 155]
ax.fill_between(months, revenue, alpha=0.3, color="#3498db")
ax.plot(months, revenue, color="#3498db", linewidth=2, marker="o", markersize=5)
ax.set_title("Monthly Revenue Trend")
ax.set_ylabel("Revenue ($K)")

# Top products (middle right)
ax = fig.add_subplot(gs[1, 2])
products = ["Product A", "Product B", "Product C", "Product D", "Product E"]
sales = [340, 280, 220, 190, 150]
colors = ["#3498db", "#2ecc71", "#e74c3c", "#f39c12", "#9b59b6"]
ax.barh(products, sales, color=colors)
ax.set_title("Top Products by Sales")
ax.invert_yaxis()

# Traffic sources (bottom left)
ax = fig.add_subplot(gs[2, 0])
sources = ["Organic", "Direct", "Social", "Referral", "Email"]
values = [42, 25, 18, 10, 5]
ax.pie(values, labels=sources, autopct="%1.0f%%", colors=colors, startangle=90)
ax.set_title("Traffic Sources")

# Daily active users (bottom center+right)
ax = fig.add_subplot(gs[2, 1:])
days = np.arange(30)
users = np.random.poisson(1200, 30) + np.linspace(0, 200, 30).astype(int)
ax.bar(days, users, color="#3498db", alpha=0.7)
ax.axhline(y=np.mean(users), color="#e74c3c", linestyle="--", label=f"Avg: {np.mean(users):.0f}")
ax.set_title("Daily Active Users (Last 30 Days)")
ax.set_xlabel("Day")
ax.legend()

plt.suptitle("Business Dashboard — March 2026", fontsize=16, fontweight="bold", y=1.01)
plt.savefig("dashboard.png", dpi=150, bbox_inches="tight")

Key Takeaways

• Matplotlib handles any chart type with full control over every element
• Seaborn excels at statistical visualization with minimal code
• Plotly creates interactive, web-ready charts
• Always remove unnecessary chart elements (top/right spines, extra gridlines)
• Color palettes matter — use colorblind-friendly palettes for accessibility
• Combine multiple plots into dashboards using GridSpec
• Save at 150+ DPI for crisp output in reports and presentations
